Key Features

  • Realistic Rock Racer chassis design
  • 3.5mm hard-anodized aluminum chassis plate
  • Integrated chassis roll cage
  • Dynamite 2800Kv brushless power system
  • Spektrum AVC® technology
  • Long-travel suspension
  • 4-link live rear axle
  • Waterproof electronics
  • Sealed, metal-gear transmission and diffs
  • Coil-over, oil-filled shocks
  • Easy-access battery compartment
  • Bolt-on body panels and interior details
  • Includes Spektrum DX2E transmitter with AVC adjustment
  • Bright LED light bar
Needed to Complete
  • (1) 7.4V 5000mAh 2S 30C LiPo or 11.1V 5000mAh 3S 30C LiPo: Hardcase with EC3® connector battery
  • (1) LiPo Charger
What's in the box?
  • (1) Rock Rey Truck
  • (1) Radio System
  • (1) User Manual

Video Overview

Overview

The 1/10th 2.2 Rock Rey Rock Racer is incredibly versatile. Not only can it take on rocks with ease, this monster can bash over pretty much anything, anywhere. Through mud and water-at staggering speeds over 40 MPH. It features AVC® technology, too.

Realistic 4WD Chassis with Long-Travel Suspension

The Rock Rey chassis is a brilliant blend of scale realism with functional 4WD capabilities. The foundation consists of a 3.5mm, hard-anodized aluminum chassis plate that is integrated with a realistic roll cage made of super-tough composite material. To this it adds a long-travel, independent front suspension and 4-link live rear axle that look and function exactly like their full-scale counterparts.

LED Light Bar

Twelve brilliant LEDs on the light bar cast more than enough light for running at night without placing a huge current demand on the battery.

Dynamite® 2800Kv Brushless Power System

The vehicle comes equipped with a Dynamite Fuze 2800Kv brushless motor and a waterproof 130A ESC. This potent combination can handle 2S or 3S LiPo batteries (sold separately) and will allow you to hurtle across the landscape at speeds of up to 40+ mph.

Sealed, Heavy Duty Metal-Gear Transmission and Diffs

The transmission, as well as the front and center diffs, are sealed against the elements and engineered to handle the abuse of a high-output brushless motor and punishing terrain. MOD 1 gears further increase the durability of this off-road beast.

Coil-Over Oil-Filled Shocks

The long-travel shocks do a fantastic job of soaking up the energy from big bumps and jumps. They also feature threaded shock bodies with adjustment collars so you can fine tune the pre-load settings of the coil-over springs. External bump stops on the rear provide plush landings on the hardest surfaces.

Waterproof Electronics

The receiver, servo and ESC are all waterproof so you can run anytime, rain or shine.

Easy-Access Motor

The motor can quickly be accessed for gear changes and servicing simply by removing three screws in the bottom of the chassis.

Easy-Access Battery Compartment

A convenient battery door in the back of the chassis makes it easy to swap batteries without having to remove the body or wrestle with battery straps.

Bolt-On Body Panels and Detailed Interior

The bolt-on body panels are incredibly durable and eliminate the need for body posts that might spoil the scale looks. You also get a molded interior that includes a driver and rider figure, both of which sport racing helmet and harness details.

The Full-Throttle Freedom of AVC® Technology

When you're ready to let the brushless motor off the chain, don't hold back. The receiver's built-in AVC (Active Vehicle Control®) system will work behind the scenes, making hundreds of tiny throttle and steering adjustments per second, so more of the motor's power is translated into ballistic speed and acceleration instead of just flying dirt. An AVC adjustment knob on the included DX2E transmitter lets you adjust how much traction control the system provides. You can even turn it off.

PRODUCT SPECS

Approximate Assembly Time
No assembly required
Ball Bearings
Yes
Body
Screened, Polycarbonate
Brakes
Electronic
Charger
Sold Separately
Chassis
3.5mm Plate, 6061-T6 Aluminum
Completion Level
Ready-To-Run
Differential
Locked Rear, gear diff front and rear
Drivetrain
4WD
Final Drive Ratio
32.30:1
Front Track
12.75 in (323.8mm)
Gear Pitch
1.0 Module
Ground Clearance
2.2 in (55.9mm) at rear diff
Motor Size
550 6-Pole 2800kv
Outer Diameter
5.75 in (146mm)
Pinion
12T
Power Type
Electric
Product Height
8.75 in (222.3mm)
Product Length
20.75 in (527mm)
Product Weight
6.55 lb (3.0kg)
Product Width
12.75 in (323.8mm)
Radio
Included
Rear Track
12.75 in (323.8mm)
Receiver
Included
Scale
1/10
Servos
Included
Shock Type
Oil-Filled/Coil-Over Spring
Speed Control
Included
Suspension
Independent front/4-Link Rear
Tire Tread
Creepy Crawler
Vehicle Type
Rock Racer
Water-Resistant
Yes
Wheel Type
2.2 in (55.9mm) Glue-Type
Wheel Width
1.6 in (40.75mm)
Wheelbase
15.0 in (381mm)
